B-TECH BT8225 39" to 75" Tilting Ultra-Slim Universal TV Wall Mount (BT8225/B)

35 kg load capacity and a universal plate that accepts VESA hole patterns up to 600 x 400. Double articulated arm with three pivot points: 40 mm from the wall when folded, up to 469 mm extended, 15 degrees of tilt and 130 degrees of swivel.

  • Maximum load 35 kg
  • VESA and non-VESA fixings up to 600 x 400 mm
  • Tilt of 15 degrees either way
  • Rotation over 130 degrees, three pivot points
  • Double cantilever arm, suitable for corner mounting
  • Wall clearance from 40 mm folded to 469 mm extended
  • Tool-free tilt mechanism up to a 20 kg load
  • Sideways adjustment of the screen once fitted
  • Built-in cable management
  • Finishing covers over the fixings
  • Lockable holes to stop the screen being lifted off
  • Spirit level included to align the wall plate
  • Fits concrete, brick or stud walls
  • Hook-on installation
Ref.: BT8225/B
B-TECH BT8225 39" to 75" Tilting Ultra-Slim Universal TV Wall Mount (BT8225/B) — image 1
B-TECH BT8225 39" to 75" Tilting Ultra-Slim Universal TV Wall Mount (BT8225/B) — image 2
B-TECH BT8225 39" to 75" Tilting Ultra-Slim Universal TV Wall Mount (BT8225/B) — image 3
B-TECH BT8225 39" to 75" Tilting Ultra-Slim Universal TV Wall Mount (BT8225/B) — image 4

Non-contractual photos

The visuals on this page are supplied by the manufacturer. They are frequently produced for a whole range — not for the exact model you are viewing: what you see in the photo is never a promise of what is included.

No exchange, return or cancellation will be accepted on the grounds that something seen in a photo (accessory, port, colour, keyboard layout, packaging…) is not found on the delivered product. Only the specifications written on the page are binding for the order.

What the image does not guarantee:

  • On-screen image : the content visible on the screen is a composite: it represents neither the real picture quality nor any content supplied with the product.
  • Stand and mount : the shape of the stand changes between versions; wall mounts, arms and ceiling fixings are not included unless stated.
  • Connectors and sound : the number of HDMI, DisplayPort and USB ports, and the presence of speakers, a tuner or a network port, are read in the specifications.
  • Panel : bezels, curved format, touch, matte or glossy finish and refresh rate cannot be judged from a photo.
  • Accessories : remote control, cables, 3D glasses and projection screen are supplied only if the specifications say so.
  • Colour : one image often serves several colours, and the shade you see depends on studio lighting as much as on your screen settings; the colour sold is the one in the title and the specifications.
  • Props and accessories : the items shown around the product (cables, stands, decorative objects, content displayed on screen) are not included unless explicitly stated.
  • Packaging : boxes, labels and bundles change with the manufacturer's revisions: the packaging delivered may differ from the one in the photo.

What is binding: the product title, this page's technical specifications, the description and, when provided, the manufacturer's PDF datasheet available in the downloads.

The slightest doubt about a specification? Contact us before ordering and we will check for you.

(+212) 05 30 31 64 21+212 6 64 10 46 24service.client@iris.ma

See our terms and conditions of sale.

1/4
3 799,00 DHincl. VAT

Limited quantity

Quantity
Order on WhatsAppOn WhatsAppQuick reply

Earn 38 DH in loyalty credit with this purchaseHow does it work?Loyalty credit capped at 300 DH per order.

Receive it between Wed 23 Sept and Fri 25 Sept — free delivery all over Morocco

Delivery to your address

Receive it between Wed 23 Sept and Fri 25 Sept — free delivery all over Morocco

The estimate is refined using actual delivery rounds to your city.

  • Free delivery from 3 000 DH of purchases, all over Morocco.
  • Below that, the same rate in every city for parcels up to 30 kg (delivery to your home or workplace) — the exact amount is shown above, then in the basket.
  • Above 30 kg, the rate follows the parcel's weight. In Casablanca, the flat rate holds up to 120 kg.
  • You are notified by SMS, then called by the courier before your parcel is handed over (delivered by Sapress).
  • Observed delivery time: 1 to 5 working days depending on the city.
Free in-store collection: Casablanca (within 24 h) · Témara (within 48 h)

In-store collection — free

Casablanca store
We bring it to the store within 24 h
We call you as soon as it arrives in store.

Résidence Manoir des Roses, Lot. 18, Boulevard El Hachmi El Filali, Rond-point Bachkou, Casablanca

Opening hours

  • Mon–Fri: 10am – 7pm
  • Sat: 10am – 2pm
  • Closed on Sundays and public holidays

Payment on site: cash, bank card via terminal, certified cheque.

View the map on Google Maps

Temara pickup point
We bring it to the store within 48 h
We call you as soon as it arrives in store.

Boulevard Hassan II, Résidence Les Perles de Témara, Immeuble 5, appartement 2, Témara

Opening hours

  • Mon–Fri: 8.30am – 1pm / 2pm – 6pm
  • Sat: 8.30am – 12.30pm
  • Closed on Sundays and public holidays

Payment on site: cash, bank card via terminal, certified cheque.

View the map on Google Maps

1 year warranty — free repair in Morocco if it breaks down during the warranty period

1 year manufacturer's warranty

This product is covered for 1 year by a manufacturer's warranty (the brand's official warranty). Your iris.ma invoice serves as the warranty document: keep it safe.

A problem with your product? Don't worry: contact us by phone, WhatsApp or e-mail. Depending on the brand, we direct you either straight to the repairer appointed by the brand to fix your product, or to us — and we take care of the rest.

  • If a repair is possible, it is carried out free of charge.
  • If the product cannot be repaired, the brand offers an exchange for another product.
  • If no product is available, a refund is issued as soon as the brand confirms it.

Faulty straight out of the box? Some brands offer an immediate exchange, others a repair. Contact us to find out what applies to your product.

The warranty covers breakdowns occurring under normal use, as defined by the brand's terms. Product breakage (drop, impact, liquid…) is not covered, nor are certain consumable parts.

(+212) 05 30 31 64 21+212 6 64 10 46 24service.client@iris.ma

New, never opened — our commitment

All our products are new, delivered in their sealed original packaging.

We commit to never sending you a product that has been opened, unboxed or returned by another customer — even one “just opened for checking”.

Any doubt on delivery (damaged box, seal already opened)? Point it out to the courier or contact us immediately: we take the product back and send you another one.

Sales invoice

Every order comes with its sales invoice, included with the parcel (handed over in person for a store collection).

Ordering for a company? Using the details you give at checkout (company name and ICE), the invoice is issued in your company's name, with its ICE.

Need a quote? Request a free quote — reply within 24 working hours.

100% secure payment: Bank transfer · Bank card · Cash on delivery · Certified cheque

Accepted payment methods

Bank transfer

Simply transfer the amount shown to account 007 826 0002684000000426 89 — SGM2I, Attijariwafa bank. The rest (the reference to quote, sending us the proof, tracking) is explained right after confirmation and by email. An instant transfer is recommended: it saves you 24 hours on the delivery time.

Bank card

Your everyday Moroccan bank card is enough — Visa, Mastercard or CMI, no special card required. Foreign cards are accepted too. Secure payment by Attijari Payment.

Cash on delivery

Pay the courier in cash on delivery — no fee.

Certified cheque

Certified cheque payable to “sgm2i”. Have your bank certify the cheque, then send us a copy on WhatsApp (+212 6 64 10 46 24) or to service.client@iris.ma — we dispatch as soon as we receive it.

Cash at a bank branch

Pay the cash in at any of the 3,400 Attijariwafa Bank branches in Morocco, to the SGM2I account no. 0268 D 000 000 426. You do not need an account there: your ID and the cash are enough.

The methods offered depend on the order total and the carrier — checkout shows the final list.

Google reviews4.7(553 reviews)
Manufacturer's datasheetView the PDF · 1,3 Mo — downloadable

Product overview

Gain flexibility with the B-TECH BT8225 tilting TV wall mount, designed for 39- to 75-inch screens. Its ultra-slim structure with dual articulating arms allows installation close to the wall (just 4 cm), while extending up to 47 cm. With ±15° tilt and 130° swivel, you always get the best viewing angle. This universal mount accepts VESA patterns up to 600 x 400 and features a cable management system for a tidy finish. Ideal for home or business installations, it combines sturdiness, security and good looks.

See all the specifications ↓
Request a quote

Be notified of a price drop

Share:

Technical specifications

Technical specifications
Colour(s)Black
Anti-theft protectionArms drilled for a padlock (padlock not included)
MountingWall: concrete, brick and stud partition (16-inch stud spacing)
Post-installation adjustmentsLateral screen adjustment once hung
VESA patternUp to 600 x 400 mm
Product typeDual-arm swivel and tilt wall mount
Compatible screen sizes39 to 75 inches
Technical specifications (continued)
Tilt angle+/- 15°
Swivel and rotation130° swivel
Distance from wall40 to 469 mm
Cable routingIntegrated cable management
Included mounting hardwareYes, all mounting hardware is included
Warranty1 year

Downloads

Customer reviews

No reviews yet

Be the first to review this product and help other customers.

Write a review
Your rating
5/5

Shown publicly with your review.

Never published — a confirmation email will be sent to you.

Tell us about the product — in a few lines:

  • what you liked in everyday use;
  • the quality and performance you found;
  • who you would recommend it to, and why.

A question about an order, a delivery or a payment? Write to us and we will reply to you directly.

Under Law 09-08, you have the right to access, rectify and object to the processing of your personal data. This processing has been authorised by the CNDP under no. D-CE-389/2015. Learn more

Frequently asked questions about this product

What load does the B-TECH BT8225 mount really take?
35 kg in normal use, but only 20 kg if you want to keep tool-free tilt. Two limits, two uses: above 20 kg, adjusting the tilt means going back to the screws. This is the point to settle before ordering.
How far from the wall does the BT8225 mount hold the screen?
From 40 mm retracted to 469 mm extended. Retracted, it gives the flat look sought in a neat installation; extended, it gives full access to the rear connections without taking the TV down.
Is the B-TECH BT8225 mount suitable for corner mounting?
Yes. Its dual cantilever arm with three pivot points and its 130° rotation are explicitly designed for corner mounting: the screen faces the room while the wall plate is fixed in the corner.
What type of wall can the B-TECH BT8225 be fixed to?
It is specified for concrete, brick and stud walls. On a stud wall, the wall plate must be screwed into the studs of the frame, never into the plasterboard alone — this is what determines strength and safety.
Can you re-centre the screen after hanging it on the BT8225?
Yes, a lateral adjustment lets you slide the screen once it is in place. A spirit level is supplied to align the wall plate when drilling: together, these two features spare you a complete reinstallation if the mount ends up slightly crooked.
Is the BT8225 mount compatible with a screen without a VESA hole pattern?
Yes. It accepts VESA and non-VESA fixings up to 600 x 400 mm, which also covers panels whose rear hole pattern does not exactly follow the standard — a common case on large entry-level screens.
How do you protect the TV against theft on the BT8225 mount?
The arms have padlockable holes designed to prevent unauthorised removal of the screen. Finishing covers also hide the fixings, and cable management is built into the arms.
Is the B-TECH BT8225 TV mount new and under warranty?
New, part number BT8225/B, in black, in original B-Tech packaging. The invoice serves as the warranty document for 1 year. The manufacturer's documentation is available in the datasheet.
