UNV XVR301-08Q3 DVR Video Recorder

8 video channels with 1 SATA interface (hard drive up to 8 TB) and support for P2P, UPnP, DDNS and HTTPS for remote access.

  • 8 video channels
  • 1 SATA interface (up to 8 TB per drive)
  • Network protocols: TCP/IP, P2P, UPnP, DDNS, HTTPS
Ref.: XVR301-08Q3
New
UNV XVR301-08Q3 DVR Video Recorder — image 1
UNV XVR301-08Q3 DVR Video Recorder — image 2
UNV XVR301-08Q3 DVR Video Recorder — image 3

Non-contractual photos

The visuals on this page are supplied by the manufacturer. They are frequently produced for a whole range — not for the exact model you are viewing: what you see in the photo is never a promise of what is included.

No exchange, return or cancellation will be accepted on the grounds that something seen in a photo (accessory, port, colour, keyboard layout, packaging…) is not found on the delivered product. Only the specifications written on the page are binding for the order.

What the image does not guarantee:

  • Hard drive : NVR and DVR recorders ship without a hard drive, unless explicitly stated.
  • Kits : an image showing several cameras, a recorder and a monitor commits nothing about the contents of the box — see the title and the specifications.
  • Accessories : mounts, power supplies, cables, PoE injectors and memory cards are supplied only if the specifications say so.
  • Specifications : resolution, lens, infrared range and power mode vary between models of a single series.
  • Colour : one image often serves several colours, and the shade you see depends on studio lighting as much as on your screen settings; the colour sold is the one in the title and the specifications.
  • Props and accessories : the items shown around the product (cables, stands, decorative objects, content displayed on screen) are not included unless explicitly stated.
  • Packaging : boxes, labels and bundles change with the manufacturer's revisions: the packaging delivered may differ from the one in the photo.

What is binding: the product title, this page's technical specifications, the description and, when provided, the manufacturer's PDF datasheet available in the downloads.

The slightest doubt about a specification? Contact us before ordering and we will check for you.

+212 6 64 10 46 24service.client@iris.ma

See our terms and conditions of sale.

1/3
829,00 DHincl. VAT

Out of stock

Under Law 09-08, you have the right to access, rectify and object to the processing of your personal data. This processing has been authorised by the CNDP under no. D-CE-389/2015. Learn more

Can’t wait?

Ask for an alternative on WhatsApp

Quick reply

Product overview

The XVR301-08Q3 is a 8-channel digital video recorder (DVR) from Uniview, designed to centralise recording and viewing of cameras

  • Number of channels: 8
  • Product type: DVR recorder
  • Protocols: TCP/IP;P2P;UPnP;DHCP;HTTP;HTTPS;DNS;DDNS;SMTP
  • SATA interfaces: 1 SATA interface
  • Capacity: Up to 8 TB per HDD (maximum HDD capacity varies with ambient temperature)
See all the specifications ↓
Request a quoteShare:

Technical specifications

Technical specifications
Smart detectionBy the recorder: Ultra Motion Detection (UMD) on 8 channels, intrusion prevention on 2 channels, face detection on 1 channel; by the IP cameras: intrusion prevention on 2 channels and face detection on all channels, up to 4 images/s in total; search by face, by behaviour and people counting report
Video compressionH.265, H.264
Decoding capacityAnalogue: 8 x 8 MP Lite at 8 fps, 8 x 3K Lite at 12 fps, 8 x 5 MP Lite at 12 fps, 8 x 4 MP Lite at 15 fps, 8 x 1080p at 15 fps; IP: 1 x 8 MP at 30 fps, 2 x 4 MP at 30 fps, 4 x 1080p at 30 fps
Outgoing bandwidth64 Mbps
Incoming bandwidth40 Mbps (up to 56 Mbps after converting all analogue channels)
Interfaces1 x RJ45 10/100 Mbps, 2 x USB 2.0 on the rear, 1 x RS-485, 1 CVBS BNC video output, 8 audio-over-coax inputs, 1 RCA audio input, 1 RCA audio output
Alarm inputs and outputs4 inputs, 1 output
Power consumption≤ 10 W without hard drive
Weight≤ 1.1 kg without hard drive
Dimensions (W x D x H)260 x 226 x 47 mm
Storage bays1 SATA bay
Power supply12 V DC / 2 A via external power adapter
CertificationsCE (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC Part 15 Subpart B, UL, RoHS, WEEE
Maximum supported capacityUp to 16 TB per drive
Technical specifications (continued)
Network protocolsONVIF, RTSP, TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP, NTP
Operating temperature-10 to 55 °C
Operating humidity≤ 90% non-condensing
Video recording resolution8 MP Lite, 5 MP Lite, 4 MP Lite, 1080p, 720p, D1
IP video inputs4 channels, up to 12 after converting all analogue inputs
Analogue video inputs8 BNC inputs
Supported analogue standardsAHD: 8 MP at 15 fps, 5 MP at 20 fps, 4 MP at 30 fps, 1080p at 30 fps, 720p at 30 fps; TVI: 8 MP at 15 fps, 3K at 20 fps, 5 MP at 20 fps, 4 MP at 30 fps, 1080p at 30 fps, 720p at 30 fps; CVI: 8 MP at 15 fps, 5 MP at 25 fps, 4 MP at 30 fps, 1080p at 30 fps, 720p at 30 fps; CVBS
Simultaneous playback8 channels
Number of channels8
HDMI output1 x HDMI, 4K (3840 x 2160) at 30 Hz, up to 1920 x 1080 at 60 Hz
VGA output1 x VGA, up to 1920 x 1080 at 60 Hz
Product typeDVR recorder
Interface language38 languages, including French and Arabic
Warranty1 year

Customer reviews

No reviews yet

Be the first to review this product and help other customers.

Write a review
Your rating
5/5

Shown publicly with your review.

Never published — a confirmation email will be sent to you.

Tell us about the product — in a few lines:

  • what you liked in everyday use;
  • the quality and performance you found;
  • who you would recommend it to, and why.

A question about an order, a delivery or a payment? Write to us and we will reply to you directly.

Under Law 09-08, you have the right to access, rectify and object to the processing of your personal data. This processing has been authorised by the CNDP under no. D-CE-389/2015. Learn more

Frequently asked questions about this product

How many cameras does the UNV XVR301-08Q3 recorder accept?
8 video channels. It centralises recording and viewing of the cameras on a single site, and can be managed both from the device itself and remotely, within a Uniview video surveillance system.
What hard drive can be installed in the XVR301-08Q3?
It has one SATA interface, for a disk of 8 TB maximum. The recording retention period then depends on the number of cameras connected, their resolution and the recording mode — continuous or triggered.
Is the stated 8 TB capacity always achievable?
Not under all conditions: the maximum capacity actually supported varies with the ambient temperature of the room. A recorder installed in a hot, poorly ventilated room sees its margin shrink — a factor to take into account when choosing where to install it.
How can the XVR301-08Q3 be reached from outside the site?
Through P2P, which sets up the connection without configuring the router, or through DDNS, which keeps the recorder reachable despite a changing public IP address. UPnP takes care of opening the ports if needed.
Can remote viewing be encrypted?
Yes, with HTTPS. This is the setting to enable as soon as the recorder can be reached from the Internet: over plain HTTP, login credentials and images travel unencrypted across the network, within reach of anyone listening in on the connection.
Can the recorder send an e-mail notification when an event occurs?
It supports the SMTP protocol, which lets a device send e-mail. This is how a recorder reports motion detection or loss of signal from a camera, without you having to open the interface.
Is the UNV XVR301-08Q3 recorder new and under warranty?
New, reference XVR301-08Q3, in original Uniview packaging. The invoice serves as the warranty document for 1 year. Keep it: it is the document that will be requested if you make a claim.
