Aruba Instant On 1430 5G Switch (R8R44A)
Ultra-compact, silent, plug-and-play switch, ready to extend an isolated workstation, an individual office or a small working area, with no configuration at all.
- Unmanaged: plug-and-play operation, no configuration needed
- Ultra-compact format (93 × 116 × 26 mm), desk, wall or under-table mounting
- Fanless operation, complete silence
- Switching capacity 10 Gbps, throughput 7.44 Mpps
- Automatic QoS for voice and video, with no setting to adjust
- Auto-negotiation and Auto MDI/MDI-X on every port
- Powered by an external mains adapter
Ref.: R8R44A
Back to school
-4%699,00 DHincl. VAT729,00 DH
You save 30,00 DH incl. VAT
Ends in, ends in 2 days and 0 hour
Configuration · Aruba Instant On 1430
- Configuration shown: 5 × RJ45
- 8 × RJ45
- 8 × RJ45 PoE+ 64 W
- 16 × RJ45
- 16 × RJ45 PoE+ 124 W
- 24 × RJ45
- 26 × RJ45 2 × SFP
In stock
Earn 7 DH in loyalty credit with this purchaseHow does it work?Loyalty credit capped at 300 DH per order.
Receive it between Wed 23 Sept and Fri 25 Sept — delivery 40 DH incl. VAT all over Morocco
Free in-store collection: Casablanca (within 24 h) · Témara (within 48 h)
3 years warranty — free repair in Morocco if it breaks down during the warranty period
100% secure payment: Bank transfer · Bank card · Cash on delivery (deposit of 300 DH by card or bank transfer) · Certified cheque
Product overview
Unmanaged Aruba Instant On 1430 5-port Gigabit switch — an ultra-compact, silent plug-and-play solution for a single desk or workspace.
Connectivity: 5 10/100/1000BASE-T RJ45 ports — no SFP port — fanless design, completely silent operation.
No PoE: connected devices use their own power supply — ideal for a PC, printer, network display or desktop NAS.
Performance: 10 Gbps non-blocking switching capacity, 7.44 Mpps forwarding rate, 8,192-entry MAC table; automatic QoS for voice and video with no configuration.
Plug-and-play: no management interface — up and running the moment it is plugged in, powered by an external adapter.
Desktop, wall or under-desk mounting; discreet, compact format.
Ideal for micro-businesses, home offices, small meeting rooms or a one-off network extension.
Request a quoteShare:
Technical specifications
| MAC table size | 8,192 entries |
|---|---|
| Number of VLANs | None |
| Internal memory | 2 Kbit EEPROM |
| Interfaces | 5 autosensing 10/100/1000 RJ-45 ports |
| PoE ports | None |
| Total PoE budget | None |
| Network standards | IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), 802.3ab (1000BASE-T), 802.3az (Energy Efficient Ethernet) |
| Switching capacity | 10 Gbps |
| Forwarding rate | 7.44 Mpps |
| Packet buffer | 1 MB |
| Management modes | None (plug-and-play) |
| Cloud management platform | None |
| Layer 2 features | Jumbo frames up to 9,216 bytes, flow control, Energy Efficient Ethernet 802.3az |
| IP routing | None |
| Quality of service (QoS) | DSCP or IEEE 802.1p prioritisation |
| Power consumption | 12 W maximum, 1 W idle |
|---|---|
| Weight | 0.27 kg |
| Dimensions (W x D x H) | 116 x 93 x 26 mm |
| Latency | 100 Mbps: < 3.81 µs · 1 Gbps: < 0.93 µs |
| Number of ports | 5 ports or fewer |
| Managed | No |
| Security features | None |
| Power supply | External AC adapter 100-240 V AC, 50/60 Hz, 0.3 A (output 12 V DC, 1 A) |
| Cooling system | Fanless |
| Operating temperature | 0 to 40 °C |
| PoE power | No |
| Port speed | 1 Gbps (Gigabit) |
| Fibre slots (SFP) | No |
| Mounting | Desktop |
| Warranty | 3 years |
Downloads
Customer reviews
No reviews yet
Be the first to review this product and help other customers.
Write a review
Frequently asked questions about this product
Can the Instant On 1430 5G be configured or monitored?
No: it is an unmanaged switch, with no interface or app. Nothing to set up, nothing to update, nothing to monitor: it starts switching as soon as it is plugged in. It is the right choice for extending a network socket in an office, not for segmenting a network into VLANs.
How much space does this 5-port model take up on a desk?
Very little: 93 × 116 × 26 mm and 270 grams, barely more than a deck of cards. It slips behind a monitor, under a table or into a cabinet, and its passive cooling, with no fan, makes it completely silent.
How is the 1430 5G powered, and how much does it consume?
Through an external power adapter rated 12 V at 1 A, on a 100-240 V input: make sure there is a free socket nearby. Consumption peaks at 12 W and drops to 1 W at idle, with the IEEE 802.3az standard reducing power further during quiet periods.
Do voice and video get priority without any configuration?
Yes. Quality of service recognises packets marked with DSCP or IEEE 802.1p and moves them ahead of the rest of the traffic, automatically. Flow control limits packet loss when a device is saturated, which is enough to keep a VoIP call stable on a small installation.
Does this switch pass through 802.1X authentication and Spanning Tree?
Yes to both: 802.1X EAPOL frames pass through the switch, so a workstation connected behind it can authenticate with the managed device upstream; and BPDU frames are forwarded, which lets Spanning Tree detect loops above it.
Is a crossover cable needed to daisy-chain this switch to another one?
No: all five ports correct the pinout on their own thanks to automatic MDI/MDI-X, whether the cable is straight-through or crossover. Auto-negotiation detects 10, 100 or 1,000 Mbps; at Gigabit, the link necessarily runs in full duplex, which doubles the effective throughput of each port.
What performance can be expected from such a small switch?
10 Gbps switching capacity, a 7.44 Mpps forwarding rate and latency below 0.93 µs at Gigabit, the lowest in the 1430 series. It accepts jumbo frames of up to 9,216 bytes, stores 8,192 MAC addresses and operates from 0 to 40 °C.
Is the switch new and covered by a warranty?
Yes, new equipment, with a 3-year warranty, the invoice serving as the warranty document. The manufacturer's document covers the whole 1430 series and lets you compare this 5-port model with the 8, 16, 24 and 26-port versions: datasheet (PDF).
