Aruba Instant On 1430 16G Class 4 PoE 124 W Switch (R8R48A)
Plug-and-play switch that powers a whole fleet of Wi-Fi access points, IP cameras or VoIP phones over Power over Ethernet, with no network configuration and no dedicated IT team.
- Unmanaged: plug-and-play operation, no configuration needed
- All 16 ports deliver up to 30 W each (IEEE 802.3af/at, class 4)
- Dynamic PoE power sharing between the connected devices
- Fanless operation, complete silence
- Switching capacity 32 Gbps, throughput 23.8 Mpps
- Auto-negotiation and Auto MDI/MDI-X on every port
- Internal power supply, 19-inch rack mounting (kit included)
Ref.: R8R48A
5 799,00 DHincl. VAT
Configuration · Aruba Instant On 1430
- 5 × RJ45
- 8 × RJ45
- 8 × RJ45 PoE+ 64 W
- 16 × RJ45
- Configuration shown: 16 × RJ45 PoE+ 124 W
- 24 × RJ45
- 26 × RJ45 2 × SFP
In stock
Earn 58 DH in loyalty credit with this purchaseHow does it work?Loyalty credit capped at 300 DH per order.
Receive it between Wed 23 Sept and Fri 25 Sept — free delivery all over Morocco
Free in-store collection: Casablanca (within 24 h) · Témara (within 48 h)
3 years warranty — free repair in Morocco if it breaks down during the warranty period
100% secure payment: Bank transfer · Bank card · Cash on delivery (deposit of 870 DH by card or bank transfer) · Certified cheque
Product overview
The Aruba Instant On 1430 16G PoE 124W is a fully PoE+ plug-and-play switch designed to deploy Wi-Fi access points, IP cameras and VoIP phones in SMEs or small offices, with no network configuration at all.
16 Gigabit RJ45 ports, all able to power Class 4 PoE devices: each port delivers up to 30 W in line with the IEEE 802.3af and 802.3at standards, for a total budget of 124 W allocated dynamically across connected devices.
Unmanaged (Plug & Play): no configuration required, up and running immediately once plugged in — ideal for sites without a dedicated IT team.
Silent, fanless operation, suited to noise-sensitive office environments.
32 Gbps switching capacity, 23.8 Mpps forwarding rate, 8,192-entry MAC table. Ref. R8R48A.
Request a quoteShare:
Technical specifications
| MAC table size | 8,192 entries |
|---|---|
| Number of VLANs | None |
| Internal memory | 128 Kbit EEPROM |
| Interfaces | 16 Class 4 PoE autosensing 10/100/1000 RJ-45 ports |
| PoE ports | 16 Class 4 PoE ports (802.3af/at), up to 30 W per port |
| Total PoE budget | 124 W |
| Network standards | IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), 802.3ab (1000BASE-T), 802.3az (Energy Efficient Ethernet), 802.3af, 802.3at |
| Switching capacity | 32 Gbps |
| Forwarding rate | 23.80 Mpps |
| Packet buffer | 2 MB |
| Management modes | None (plug-and-play) |
| Cloud management platform | None |
| Layer 2 features | Jumbo frames up to 9,216 bytes, flow control, Energy Efficient Ethernet 802.3az |
| IP routing | None |
| Quality of service (QoS) | DSCP or IEEE 802.1p prioritisation |
| Power consumption | 147 W maximum, 5 W idle |
| Weight | 2.09 kg |
| Dimensions (W x D x H) | 275 x 260 x 44 mm |
|---|---|
| Package contents | 2-post rack mounting kit included, mounting brackets supplied |
| Latency | 100 Mbps: < 2.7 µs · 1 Gbps: < 1.80 µs |
| Number of ports | 11 to 18 ports |
| Managed | No |
| Security features | None |
| Power supply | Internal power supply 100-127 V AC / 200-240 V AC, 50/60 Hz, 1.7 A/0.8 A |
| Cooling system | Fanless |
| Operating temperature | 0 to 40 °C |
| PoE power | Yes |
| Port speed | 1 Gbps (Gigabit) |
| PoE standard | PoE+ (802.3at, up to 30 W/port) |
| PoE budget | 66 to 130 W |
| Fibre slots (SFP) | No |
| Mounting | 19-inch rack-mountable |
| Warranty | 3 years |
Downloads
Customer reviews
No reviews yet
Be the first to review this product and help other customers.
Write a review
Frequently asked questions about this product
How many devices can the 124 W of PoE power?
Four 30 W devices, or a dozen 10 W cameras: the 124 W is shared across the 16 Class 4 PoE ports. 15.4 W 802.3af devices are supported in the same way. The number of ports is not the limit; the budget is.
Can this 16-port PoE model be configured?
No: the 1430 is an unmanaged switch, with no management interface. No VLANs, no port settings, no monitoring: it powers devices and switches traffic as soon as it is plugged in. That is the series' deliberate trade-off: total simplicity in exchange for no control.
Is a 16-port PoE switch noisy?
No, not at all: the entire 1430 series is designed without a fan, PoE models included; cooling is passive. That is what allows it to be installed in a meeting room or a busy office, where a model with a fan would be unbearable.
How much electrical power does this switch require?
147 W maximum (including the 124 W of PoE) and only 5 W at idle, on a 100-127 or 200-240 V input. The power supply is built into the chassis: no external adapter to find room for; a simple power cable is all it takes.
Do 802.1X authentication frames pass through this switch?
Yes: 802.1X EAPOL frames are forwarded, so a workstation connected behind it can authenticate with the managed switch upstream. BPDU frames also pass through, which lets Spanning Tree detect loops above it.
Do voice and video get priority without any configuration?
Yes. Quality of service recognises packets marked with DSCP or IEEE 802.1p and moves them ahead of the rest of the traffic, automatically. Flow control also limits packet loss when a network node is congested.
What performance and footprint does this 16-port model offer?
32 Gbps capacity, 23.80 Mpps and latency below 1.80 µs at Gigabit, with 8,192 MAC addresses and a 2 MB buffer. The chassis measures 275 mm wide, 260 mm deep and 44 mm high, and weighs 2.09 kg.
Do jumbo frames pass through for heavy transfers?
Yes, up to 9,216 bytes, which speeds up large copies to a NAS. The IEEE 802.3az standard also reduces consumption during quiet periods, and the switch handles 0 to 40 °C at altitudes of up to 3 km.
Is the switch new and covered by a warranty?
Yes, new equipment, with a 3-year warranty, the invoice serving as the warranty document. The manufacturer's document details the seven models in the 1430 series and their respective PoE budgets: datasheet (PDF).
