Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624)

Three Gigabit network sockets on hand, two of which power an IP phone or a set-top box over PoE. Up to 1,733 Mbps on the 5 GHz band and 200 devices served at the same time.

  • 1 incoming Gigabit port with PoE/PoE+ and 3 outgoing Gigabit ports
  • 2 of the outgoing ports supply PoE, 6 W per port
  • Up to 1,733 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
  • Up to 200 devices served at the same time
  • Powered by PoE (802.3af) or PoE+ (802.3at), automatic detection
  • Range claimed at up to 100 m
  • Built-in controller: drives up to 30 GWN access points with no dedicated hardware
  • Free, unlimited cloud management, or software management through GWN Manager
  • Mesh network and captive portal
  • WPA3 and WPA/WPA2 Enterprise encryption
  • 16 Wi-Fi networks (SSIDs) in total, 8 per band
  • Advanced QoS for voice over Wi-Fi and real-time applications
  • Secure boot, unique certificate and random default password
  • Wall recessed mounting, 135 × 86 × 38.5 mm
Ref.: GWN7624
Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624) — image 1
Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624) — image 2
Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624) — image 3
Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624) — image 4
Grandstream WiFi 5 Access Point Dual-Band 2.4G 2×2:2 / 5G 4×4:4 MU-MIMO (GWN7624) — image 5

Non-contractual photos

The visuals on this page are supplied by the manufacturer. They are frequently produced for a whole range — not for the exact model you are viewing: what you see in the photo is never a promise of what is included.

No exchange, return or cancellation will be accepted on the grounds that something seen in a photo (accessory, port, colour, keyboard layout, packaging…) is not found on the delivered product. Only the specifications written on the page are binding for the order.

What the image does not guarantee:

  • Ports : the number and type of ports (RJ45, SFP, PoE) differ between models of a single series, which nevertheless shares one photo.
  • Antennas : their number, gain and whether they can be removed depend on the reference.
  • Modules and cables : SFP modules, transceivers, DAC cables, PoE injectors and rack-mounting kits are not included unless stated.
  • Power : some equipment is powered over PoE and shipped without a power adapter.
  • Colour : one image often serves several colours, and the shade you see depends on studio lighting as much as on your screen settings; the colour sold is the one in the title and the specifications.
  • Props and accessories : the items shown around the product (cables, stands, decorative objects, content displayed on screen) are not included unless explicitly stated.
  • Packaging : boxes, labels and bundles change with the manufacturer's revisions: the packaging delivered may differ from the one in the photo.

What is binding: the product title, this page's technical specifications, the description and, when provided, the manufacturer's PDF datasheet available in the downloads.

The slightest doubt about a specification? Contact us before ordering and we will check for you.

+212 6 64 10 46 24service.client@iris.ma

See our terms and conditions of sale.

1/5
1 019,00 DHincl. VAT

Out of stock

Under Law 09-08, you have the right to access, rectify and object to the processing of your personal data. This processing has been authorised by the CNDP under no. D-CE-389/2015. Learn more

Can’t wait?

Ask for an alternative on WhatsApp

Quick reply

Manufacturer's datasheetView the PDF · 646 Ko — downloadable

Product overview

Grandstream GWN7624 wall-mount Wi-Fi 5 access point: connect IP phones, computers and TVs from a wall socket, with Wi-Fi and 4 wired Gigabit ports.
Wi-Fi & speed: Wi-Fi 5 (802.11ac) dual-band — up to 300 Mbps (2x2:2 2.4 GHz) and 1,733 Mbps (4x4:4 5 GHz), i.e. 2.03 Gbps combined.
Capacity & performance: 4×4:4 MU-MIMO on 5 GHz, advanced QoS — up to 200 concurrent devices.
Installation: indoor; wall mounting (recessed into the wall), discreet design.
Ports & power: 1 GE uplink port (PoE IN) + 2 GE ports with PSE + 1 GE port — powered by PoE+ (802.3at).
Management: built-in controller (up to 30 local APs) + GWN.Cloud (unlimited) + GWN Manager; mesh and captive portal.
Ideal for hotels, hospitals, offices, residences and shops that want to combine Wi-Fi and wired ports on a wall plate.
Robust Wi-Fi 5 with built-in PoE OUT ports: complete connectivity from a single wall point.

See all the specifications ↓
Request a quoteShare:

Technical specifications

Technical specifications
Package contentsGWN7624 access point, 4 screws (KB 3.5 x 26), quick setup guide
Number of SSIDs16 SSIDs in total, 8 per radio
Interfaces1 x 10/100/1000 Ethernet uplink port with PoE and PoE+, 2 x 10/100/1000 Ethernet ports with PoE output (PSE), 1 x 10/100/1000 Ethernet port, 1 reset pinhole
Network standardsIEEE 802.11a/b/g/n/ac, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
Advanced Wi-Fi technologiesAutomatic power adaptation on PoE or PoE+ detection
Maximum channel width80 MHz on 5 GHz, 40 MHz on 2.4 GHz
Spatial streams and MU-MIMO2×2:2 MIMO at 2.4 GHz, 4×4:4 MU-MIMO at 5 GHz
Maximum Wi-Fi throughput per band300 Mbps at 2.4 GHz, 1,733 Mbps at 5 GHz
Management modesController built into the web interface (30 access points), GDMS Networking, GWN Manager
Cloud management platformGDMS Networking
Layer 2 featuresVLAN, 802.1Q, 802.1p, 802.11e/WMM and TOS quality of service
Power consumption25 W maximum
Dimensions (W x D x H)135 x 86 x 38.5 mm
Antennas2 internal 5 GHz antennas and 2 internal dual-band antennas, gain 3 dBi at 2.4 GHz and 5 dBi at 5 GHz
Technical specifications (continued)
Stated rangeUp to 100 m
Maximum transmit power23 dBm on 2.4 GHz, 25 dBm on 5 GHz
Security featuresWEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), WPA3, secure boot, unique certificate
Power supplyPoE 802.3af or PoE+ 802.3at, 802.3az compatible; 6 W PSE output per port
Operating temperature-10 to 50 °C
Operating humidity5 to 95% non-condensing
Wi-Fi standardWi-Fi 5
LocationIndoor
Mounting typeWall mount
BandsDual-band
PoE powerPoE+ (802.3at)
Simultaneously connected devicesUp to 200 concurrent clients
Warranty1 year

Downloads

Customer reviews

No reviews yet

Be the first to review this product and help other customers.

Write a review
Your rating
5/5

Shown publicly with your review.

Never published — a confirmation email will be sent to you.

Tell us about the product — in a few lines:

  • what you liked in everyday use;
  • the quality and performance you found;
  • who you would recommend it to, and why.

A question about an order, a delivery or a payment? Write to us and we will reply to you directly.

Under Law 09-08, you have the right to access, rectify and object to the processing of your personal data. This processing has been authorised by the CNDP under no. D-CE-389/2015. Learn more

Frequently asked questions about this product

Can the GWN7624 power an IP phone over the network?
Yes, two of its Gigabit ports pass PoE through, with 6 W per port. That is enough to power an IP phone or a small sensor from the wall plate, with no power outlet needed in the room.
How many network sockets does the GWN7624 provide?
Four Gigabit ports: an uplink port that receives PoE and connects the access point to the network, two ports that pass PoE through, and a fourth data port. Phone, TV and desktop computer can therefore be connected directly to the wall plate.
What power supply does the GWN7624 need?
A PoE+ 802.3at port: total power draw can reach 25 W when both PoE outputs are powering devices. The access point also supports the 802.3az energy-saving standard.
What difference does the 4x4 on the GWN7624's 5 GHz band make?
Four radio chains on the 5 GHz band — versus two on 2.4 GHz: the data rate there reaches 1,733 Mbps, for a combined 2.03 Gbps. That is a high level for a wall-mounted access point, served by two 5 GHz antennas and two internal dual-band antennas.
How many devices does the GWN7624 serve at the same time?
Up to 200 simultaneous devices. That is well beyond the needs of a room or an office: the headroom is useful in a meeting room or a shared space equipped with a single wall-mounted access point.
How many Wi-Fi networks can be created on the GWN7624?
16 SSIDs in total, 8 per band, with captive portal and VLAN segmentation. A room, a department and guest access can thus coexist on the same wall plate.
Does the GWN7624 support WPA3?
Yes, in addition to WPA2-PSK and WPA/WPA2 Enterprise with TKIP or AES. The hardware boots on signed firmware, and each access point leaves the factory with its own certificate and its own unique random password.
Do you need a controller to manage several GWN7624 units?
No. A controller is built into the web interface of the access point and manages up to 30 local GWN access points, with no licence. GDMS Networking manages a fleet of devices in the cloud free of charge, and GWN Manager does so on your own servers.
How much wall space does the GWN7624 take up?
135 × 86 × 38.5 mm, designed to be flush-mounted in the wall: the installation is neat, with no visible housing. This is the format chosen in hotels and healthcare facilities, where the access point needs to go unnoticed.
Is the GWN7624 suitable for Wi-Fi IP phones?
Yes, it is in fact what it is designed for: advanced QoS reserves bandwidth for real-time traffic, and its PoE ports also power a wired phone in the same room.
Under what conditions does the GWN7624 operate?
Indoors, between -10 and 50 °C — a wider range than the average wall-mounted access point, which starts at 0 °C. This allows installation in an unheated room or a stairwell.
Is the equipment new and covered by a warranty?
Yes, new equipment, with the invoice serving as the warranty document for one year. The manufacturer's specifications are set out in this document: GWN7624 (PDF).
