Zyxel XMG1915-18EP Managed Switch - 16 x 2.5GbE Ports with 2 SFP+ / PoE++ Uplinks (XMG1915-18EP-EU0101F)
16 Multi-Gigabit 2.5G ports in all, 8 of them PoE++ for your Wi-Fi 6/6E access points and cameras: the rack-mountable format for a small server room. Management through the Nebula cloud or a web interface.
16 x 2.5G ports in all: 8 PoE++ (60 W) and 8 standard
180 W PoE budget in actual consumption mode
Compatible with Wi-Fi 6/6E access points and PTZ cameras
Smart managed: VLAN, QoS, IGMP snooping, LACP
Nebula cloud (NebulaFlex) or local web interface
19" 1U rack-mountable, near-silent variable-speed fan
Multi-Gigabit switch Zyxel XMG1915-18EP: 16 × 2.5G ports, 8 of them PoE++, and 2 × 10G SFP+ links to connect Wi-Fi 6/6E access points and power cameras and IP phones in an office or small meeting room. Multi-Gig PoE++:8 × 2.5G PoE++ RJ-45 ports (IEEE 802.3bt, up to 60 W/port) for Wi-Fi 6E access points and PTZ cameras, plus 8 × 2.5G RJ-45 ports for workstations and NAS — over existing Cat 5e cabling. 180 W PoE budget in real-consumption mode. Uplinks:2 × 10G SFP+ slots for fibre or DAC links to an aggregation switch or a 10G NAS server. Management: smart managed; VLAN, QoS, IGMP snooping, LACP; local web interface or Nebula cloud (NebulaFlex). Variable-speed fan (19 dBA min), near-silent operation. Form factor: 19" 1U rack-mount (330 × 230 × 44 mm). Key specs: 120 Gbit/s switching, 89.2 Mpps forwarding rate, 16K MAC table.
Static and inter-VLAN routing, 8 routes, 8 IP interfaces, table of 128 IPv4 and 128 IPv6 entries
Quality of service (QoS)
8 hardware queues per port, 802.1p SPQ/WRR scheduling, storm control, ingress and egress per-port rate limiting
Power consumption
226.5 W maximum with PoE, 46.5 W without PoE, 14.52 W idle
Technical specifications (continued)
Weight
2.6 kg
Dimensions (W x D x H)
330 x 230 x 44 mm
Package contents
Power cord, rack-mount kit
Number of ports
11 to 18 ports
Managed
Yes
Security features
Layer 2 MAC filtering, static MAC, SSH v2, SSL, SHA-2 HTTPS certificate, port security, MAC freeze, CPU protection, RADIUS authentication and authorisation
Be the first to review this product and help other customers.
Write a review
Frequently asked questions about this product
How many ports on the Zyxel XMG1915-18EP supply PoE++?
Eight of the sixteen 2.5G ports, with 802.3bt PoE++ at up to 60 W each and a 180 W budget in actual-consumption mode. The other eight 2.5G ports are for workstations and network storage.
Do you need to rewire to get 2.5 Gbps?
No: 2.5 Gbps runs over the Cat 5e cabling already in place. Wi-Fi 6 or 6E access points and computers fitted with a multi-Gigabit card deliver their full performance without touching the in-wall cabling.
What are the two SFP+ slots for?
For the 10 Gbps uplink, over fibre or DAC cable, to an aggregation switch or a 10G storage server. Sixteen 2.5 Gbps ports would quickly saturate a narrower uplink.
Is this switch noisy?
It has a variable-speed fan, from 19 dBA: almost inaudible at low load. It only speeds up when delivering PoE heats up the housing.
What can you configure on this switch?
VLANs, quality of service, IGMP snooping and LACP aggregation, from the local web interface or the Nebula cloud. NebulaFlex technology lets you switch from one mode to the other without changing hardware.
What performance does this switch deliver?
120 Gbps of switching capacity and 89.2 Mpps, with a 16,000-entry MAC address table. The sixteen 2.5 Gbps ports and the two 10 Gbps links can therefore all work at the same time without a bottleneck.
How much rack space does this switch take up?
330 × 230 × 44 mm: 1U high, 23 cm deep, for 19-inch rack mounting. Its compact size means it fits in a well-ventilated wall cabinet.
Is the switch new and covered by a warranty?
Yes, new equipment, with the invoice serving as the warranty document. Full technical details are in the XMG1915-18EP datasheet.
